Sierra 18-8205 Transom Seal Kit

Sierra 18-8205 Mercruiser Alpha Gen 1 High Performance Transom Seal Kit

Sierra high-quality transom seal kit designed to meet OEM specifications. For Mercruiser 1, R/MR Alpha Gen 1 Drives with Exhaust Tube.

Seal Kit Includes:

• (1) 18-2100 Heavy Duty Gimbal Bearing
• (1) 18-2751 U-Joint Bellows
• (1) 18-2760 Exhaust Tube
• (1) 18-3601 Water Intake Hose
• (1) 18-3602 Water Intake Hose
• (1) 18-2743 Outdrive Mounting Gasket
• (2) 18-2840 Bell Housing Gasket
• (1) 18-7153 O-Ring
• (1) 18-7117 O-Ring
• (2) 18-7310 Hose Clamp
• (1) 18-7170 O-Ring
• (1) 18-7312 Hose Clamp
• (1) 18-7321 Bellows Clamp
• (1) 18-2753-1 Shift Cable Bellows

Interchangeable with:

• Mercruiser Stern Drive
• 30-803098T-1
• GLM
• 21951
• Mallory
• 9-72901
• Redline
• RL8205

Application:

Mercruiser Stern Drive

• R/MR/Alpha One (Sterndrive)
• 1983-1991
• 6225577 thru 0D469858
• R/MR/Alpha One (Transom Assembly)
• 1983-1991
• 6216687 thru 0D469858

Transom Seal Kit for MerCruiser sterndrivesFor 1;R; MR & Alpha 1 with exhaust tubeReplaces 30-803098T 1. NOTE:Replaces OEM part #MERCURY MARINE 30-803098T1For: Mercruiser I; R; MR; and Alpha I with exhaust tubeKit Contains: (1) 18-2100 Gimbal Bearing - replaces O.E. # 30-60794A4(1) 18-2751 U-Joint Bellows - replaces O.E. # 60932A4(1) 18-2760 Exhaust Tube - replaces O.E. # 78458A1(1) 18-3601 Water Intake Hose - replaces O.E. # 32-32461(1) 18-3602 Water Intake Hose - replaces O.E. # 32-41725-33(1) 18-2743 Drive Shaft Housing to Bell Housing Gasket - replaces O.E. # 27-94996-2(1) 18-2840 Bell Housing Gasket - replaces O.E. # 27-35982(1) 18-7153 O-Ring - replaces O.E. # 25-25439(1) 18-7117 O-Ring - replaces O.E. # 25-35027(2) 18-7310 Hose Clamp - replaces O.E. # NSS (1) 18-7170 O-Ring - replaces O.E. # 25-33504(1) 18-7312 Hose Clamp - replaces O.E. # NSS(1) 18-2753-1 Shift Cable Bellows - replaces O.E. # 74639(1) 18-7321 Bellows Clamp - replaces O.E. # 54-38863
